Ultra Compact AM FM Mini Mobile CB Radio
CB-40M Citizen Band Radio
$ 96.38 – $ 132.94
Share this:
Ultra Compact AM/FM Mini Mobile CB Radio 26MHz 27MHz Amateur Car radio Station
CB-40M Citizen Band Radio
Main features:
- *25.615-30.105MHz(DE version)
- *Mini and compact
- * AM/FM mode switchable
- * 9/19 emergency channel
- * 10 groups of channel for choose
- * Squelch
- * ASQ control
- * RF gain control
- * Keypad lock
- * Scan function
- * High low power
- * Reset function
- * 40Ch fixed Can not program
Specification:
- Brand: Anysecu
- Model: CB-40M
- Modulation Mode: AM/FM
- Frequency Range: 25.615-30.105MHz
- Emergency channel: 9/19
- Frequency Tolerance: ±5.0ppm
- Input Voltage: 13.2 V
- Dimensions: 109x109x28mm
- Weight: 310g with power cable
- Frequency Control: PLL Synthesizer
- Operating Temperature Range: -20℃ – +50℃
Current Drain:
- Transmit: 2A MAX
- Receive Squelched: 0.3A
- VOL Max: 0.8A
- Antenna Connector: UHF, S0239, M
Transmitter:
- Power Output Low power: 4W /High power :8W FM/AM
- Transmission interference: Inferior to 4nW(-54dBm)
- Frequency Response: 300-3000Hz
- Modulated signal distortion: Inferior to 5%
- Output Impedance: 50 ohms
Receiver:
- Sensitivity: Less than luV for 10dB (S+N)/N
- Image Rejection: 70dB
- Adjacent Channel Rejection: 60dB
- IF Frequencies: 1st 10.695MHz 2nd 455KHz
- Automatic Gain Control (AGC) Less than 10dB change in audio
- Output for inputs from 10 to 50000uV
- Squelch less than luv
- Audio Output Power :1 Watts
Frequency Response:300-3000Hz
CB-40M Default Frequency List:
-
- (DE version )
- DE frequency list 26.965 – 27.405mhz 4W 40 Channels
